Ibercisa has supplied deck machinery for the Tugboat which Cattaruzza is building with the Armón Shipyard in Vigo. The order consists of:
- One hydraulic towing winch driven by two low speed high toque, hydraulic motors with two speeds with capacity for 700 m of wire of Ø50 mm diameter and 200 m of rope Ø 100 mm diameter. This winch has a nominal line pull of 33,6 tons at 22 m/min at first layer and 165 tons of braked static capacity.
- One hidraulic anchor winch driven by a low speed, high torque, hydraulic motor with a capacity of 3,2 tons at 23 m/min and capacity for chain of Ø22 mm diameter.
- Two stoppers pawl type for Ø 22mm chain.
- One electric auxiliary winch driven by electric motor of 5,5 kW-1500 r/m, 400 V with a capacity for 150 m of wire of Ø8 mm and a nominal line pull and speed at half drum of 750 kg at 39 m/min.
- One hydraulic machine to drive the towing winch with capacity tank of 1000 liters.
